Electrical Specifications | |
Frequency Range(MHz) | 5150-5850 |
Gain(dBi) | 18.0 |
VSWR | ≤2.0 |
Polarization | ±90° |
Front to Back Ratio | ≥ 23 |
Horizontal Beam width | 20° |
Vertical Beam width | 9° |
Input Impedance | 50 Ω |
Max. Input Power | 100 W |
Lightning Protection | DC Ground |
Mechanical Specifications | |
Connector | 2xN-Female |
Dimensions(mm) | 305x305x30 |
Weight(kg) | 2.2 |
Reflector Material | Aluminum |
Radome Material | ABS |
Operating Temperature | -40°C to +65 °C |
Mounting Pole(mm) | Ø38-Ø52 |
5500MHz(H) |  |  |
5500MHz(V) |  |  |
