Electrical Specifications | ||
Frequency Range(MHz) | 2400-2500 | 5150-5850 |
Gain(dBi) | 8.0±1.0 | 10.0±1.0 |
VSWR | ≤2.0 | ≤2.0 |
Polarization | Horizontal + Vertical | Horizontal + Vertical |
Port to Port Isolation(dB) | ≥ 28 | |
Horizontal Beam width | 360° | |
Vertical Beam width | 13° | 8° |
Input Impedance | 50 Ω | |
Max. Input Power | 100 W | |
Lightning Protection | DC Ground | |
Mechanical Specifications | ||
Connector | 4xN-Female | |
Dimensions(mm) | Ø70x1180 | |
Weight(kg) | 3.8 kg | |
Radome Material | UV-PVC | |
Rated Wind Velocity | 210 km/h | |
Operating Temperature | -40°C to +65 °C | |
Mounting Pole(mm) | Ø38-Ø52 | |
2450MHz(H) |  |  |
5500MHz(V) |  |  |
