Electrical Specifications | |||
Frequency Range(MHz) | 902-928 | 902-928 | 902-928 |
Gain(dBi) | 8.0 | 8.0 | 8.0 |
VSWR | ≤1.3 | ≤1.3 | ≤1.3 |
Polarization | Circular | Horizontal | Vertical |
Horizontal Beam width | 73° | 61° | 71° |
Vertical Beam width | 62° | 72° | 63° |
Input Impedance | 50 Ω | 50 Ω | 50 Ω |
Max. Input Power | 50 W | 50 W | 50 W |
Lightning Protection | DC Ground | DC Ground | DC Ground |
Mechanical Specifications | |||
Connector | N-Female | N-Female | N-Female |
Dimensions(mm) | 260×260×42 | 260×260×42 | 260×260×42 |
Weight(kg) | 1.0 kg | 1.0 kg | 1.0 kg |
Reflector Material | Aluminum | Aluminum | Aluminum |
Radome Material | ABS | ABS | ABS |
Ingress Protection | IP65 | IP65 | IP65 |
Operating Temperature | -40°C to +65°C | -40°C to +65°C | -40°C to +65°C |
Mounting Pole(mm) | Ø38-Ø52 | Ø38-Ø52 | Ø38-Ø52 |
 |  |
| Horizontal（915MHz） | Vertical（915MHz） |
