Electrical Specifications | |||
Frequency Range(MHz) | 865-868 | 865-868 | 865-868 |
Gain(dBi) | 12.0 | 12.0 | 12.0 |
VSWR | ≤1.3 | ≤1.3 | ≤1.3 |
Polarization | Circular | Horizontal | Vertical |
Horizontal Beam width | 42° | 39° | 41° |
Vertical Beam width | 39° | 41° | 39° |
Input Impedance | 50 Ω | 50 Ω | 50 Ω |
Max. Input Power | 100 W | 100 W | 100 W |
Lightning Protection | DC Ground | DC Ground | DC Ground |
Mechanical Specifications | |||
Connector | N-Female | N-Female | N-Female |
Dimensions(mm) | 450×450×40 | 450×450×40 | 450×450×40 |
Weight(kg) | 2.0 | 2.0 | 2.0 |
Reflector Material | Aluminum | Aluminum | Aluminum |
Radome Material | UV-ABS | UV-ABS | UV-ABS |
Ingress Protection | IP65 | IP65 | IP65 |
Operating Temperature | -40°C to +60°C | -40°C to +60°C | -40°C to +60°C |
Mounting Pole(mm) | Ø38-Ø52 | Ø38-Ø52 | Ø38-Ø52 |
|  |
Horizontal（866MHz） | Vertical（866MHz） |
